A modern stadium must not only have complete sports facilities, but also has a best led stadium lights and lighting system for players and spectators.
We, OAK, have been providing professional and innovative LED stadium lights over 12 years, meeting the requirements of TV broadcast lighting, for athletes, referees, spectators, and matches.
Best quality control on main photophysical elements of led stadium lights are light color, color rendering performance, glare control and stroboscopic effect,etc..
The main technologies of led stadium lighting simulations are horizontal illuminance value, vertical illuminance value and illuminance uniformity, glare control, spill light control, meeting UEFA/FIFA lighting standard for different football stadium.
• LED Chips: CREE COB original or Bridgelux COB chips from USA.
• Power Supply: Meanwell / Inventronics optional
• Flux Efficiency: real 170~180lm/w
• Input Voltage: 100~305Vac or 277-480Vac
• Flicker Rate: <0.2% for stadium HDTV
• Control System: DALI, DMX, PWM available
• Lifetime: >100,000hrs
• Warranty: 5~10 years
● Maximum ground lighting efficiency, 5~10 times brighter than conventional lighting fixutres.
● Anti-glare system, suitable for all stadiums and sports fields.
● Precise optical TIR PC lens, optional beam angle 15°, 25°, 45°, 60°,90° for stadium and sports fields.
● Multi-angle design in lighting simulation, highest lighting uniformity.
● Low flicker rate below 0.2%, special design for stadium HDTV.
● Advanced thermal management system, groove fins design, providing 30% higher heat dissipation efficiency.
● Suitable from -40 to + 60 ° C environment temperature.
● DALI, DMX, PWM dimming available, Control panel/PC/Phone controlling optional.
MN | Power | Size | Efficiency | Beam Angle | Color | Dimming |
OAK-FL-100W | 100 | 318x255x70 | 170lm/w | 15, 25, 40, | 2700-6500K | PWM |
OAK-FL-150W | 150 | 318x320x70 | ||||
OAK-FL-200W | 200 | 418x320x70 | ||||
OAK-FL-300W | 300 | 468x436x70 | ||||
OAK-FL-400W | 400 | 568x436x70 | ||||
OAK-FL-500W | 500 | 568x501x70 | ||||
OAK-FL-600W | 600 | 568x566x70 | ||||
OAK-FL-720W | 720 | 668x566x70 | ||||
OAK-FL-800W | 800 | 668x631x70 | ||||
OAK-FL-1000W | 1000 | 718x696x70 |
1. Light source and power supply of LED stadium lights, adopting the original imported international first-line brand.
2. Radiators use military phase change heat dissipation technology and high thermal conductivity materials.
3. Color temperature is tailored for various types of stadiums and sports fields, making athletes, referees and audiences more comfortable.
4. Color rendering index is >80, which makes the color more realistic, restores the true beauty of the stadiums, and the image of ordinary LED is blurred.
5. Using professional point-by-point light distribution system, more energy-saving effect, more uniform illumination.
6. No light pollution & spillover, better glare control, effectively prevent light spill & glare, reduce over 50% light spill.
7. Constant illumination technology, lifetime >100,000 hours still keep 50% brightness.
