Tennis court lighting has different brightness requirements. OAK LED flood lights with high quality can perfectly meet the brightness requirements of indoor and outdoor tennis court lighting.
High light efficiency up to 170lm/w and CREE led COB chips from USA original & Meanwell drivers. Five Years warranty with 100% after-sales service.
CREE led COB chips from USA original & Meanwell power supply
Anti-glare system special designed for outdoor tennis court lighting projects
Color temperature range from 2700K to 5000K, color rendering index is more than 80
300w OAK LED Flood lights directly replacing traditional 1500w Metal halide Lights
DALI, DMX, PWM remote dimming systems,easy to control on&off of OAK led flood light
Using pure aluminum as the housing materials and 304/316 stainless steel brackets for OAK led flood lights
Lifetime over 100,000 hours, Five Years warranty with 100% after-sales service
Special thermal system to increase heat dissipation and extend lifespan of OAK led flood lights
For professional outdoor tennis court lighting, there are a few standards. For tennis courts with no auditoriums or only a small number of auditoriums, it is advisable to place the poles on both sides of the venue.
Tennis courts with auditoriums, high canopies and no poles, the horse-track arrangement on both sides of the site or in combination with the ceiling above the auditorium， the poles should be placed on the back side of the auditorium.
Under such lighting installation standards, tennis court flood lights require high quality. Base on the lighting standards, OAK LED manufacturer provides tennis court flood lights with different beam angles for different installation plans.
OAK tennis court flood lights can meet any tennis court lighting standards and any other outdoor sport fields lighting projects.
OAK LEDs are using 300w-2000w OAK led tennis court lights to reach standard lux level.
OAK led tennis court lights have different beam angles to give a high quality lighting performance.
CREE led COB chips from U.S. original offer high light efficiency up to 170-180lm/w.
OAK led tennis court lights with high CRI 96 optional suitable for HD photography.
IP 67 waterproof rating suitable for outdoor tennis court lighting and any other outdoor sport fields lighting project.
Each chip has individual heat sink to maintain a high stability under -40 to +60°C working environment
| MN | Power (W) | Size (mm) | Efficiency | Beam Angle (degree) | Color Temperature | Dimming Options |
| OAK-FL-100W | 100W | 318x255x70 | 170lm/w | 15, 25, 40, 60, 90, 120 | 2700-6500K | PWM DALI DMX Zigbee Manual |
| OAK-FL-200W | 200W | 418x320x70 | ||||
| OAK-FL-300W | 300W | 468x436x70 | ||||
| OAK-FL-400W | 400W | 568x436x70 | ||||
| OAK-FL-500W | 500W | 568x501x70 | ||||
| OAK-FL-600W | 600W | 568x566x70 | ||||
| OAK-FL-720W | 720W | 668x566x70 | ||||
| OAK-FL-800W | 800W | 668x631x70 | ||||
| OAK-FL-1000W | 1000W | 718x696x70 |
300W OAK LED Flood lights widely use in indoor and outdoor tennis court and others sport fields lighting projects.
Tennis court lighting has different brightness requirements. OAK LED flood lights with high quality can perfectly meet the brightness requirements of indoor and outdoor tennis court lighting.
High light efficiency up to 170lm/w and CREE led COB chips from USA original & Meanwell drivers. Five Years warranty with 100% after-sales service.
CREE led COB chips from USA original & Meanwell power supply
Anti-glare system special designed for outdoor tennis court lighting projects
Color temperature range from 2700K to 5000K, color rendering index is more than 80
300w OAK LED Flood lights directly replacing traditional 1500w Metal halide Lights
DALI, DMX, PWM remote dimming systems,easy to control on&off of OAK led flood light
Using pure aluminum as the housing materials and 304/316 stainless steel brackets for OAK led flood lights
Lifetime over 100,000 hours, Five Years warranty with 100% after-sales service
Special thermal system to increase heat dissipation and extend lifespan of OAK led flood lights
For professional outdoor tennis court lighting, there are a few standards. For tennis courts with no auditoriums or only a small number of auditoriums, it is advisable to place the poles on both sides of the venue.
Tennis courts with auditoriums, high canopies and no poles, the horse-track arrangement on both sides of the site or in combination with the ceiling above the auditorium， the poles should be placed on the back side of the auditorium.
Under such lighting installation standards, tennis court flood lights require high quality. Base on the lighting standards, OAK LED manufacturer provides tennis court flood lights with different beam angles for different installation plans.
OAK tennis court flood lights can meet any tennis court lighting standards and any other outdoor sport fields lighting projects.
OAK LEDs are using 300w-2000w OAK led tennis court lights to reach standard lux level.
OAK led tennis court lights have different beam angles to give a high quality lighting performance.
CREE led COB chips from U.S. original offer high light efficiency up to 170-180lm/w.
OAK led tennis court lights with high CRI 96 optional suitable for HD photography.
IP 67 waterproof rating suitable for outdoor tennis court lighting and any other outdoor sport fields lighting project.
Each chip has individual heat sink to maintain a high stability under -40 to +60°C working environment
| MN | Power (W) | Size (mm) | Efficiency | Beam Angle (degree) | Color Temperature | Dimming Options |
| OAK-FL-100W | 100W | 318x255x70 | 170lm/w | 15, 25, 40, 60, 90, 120 | 2700-6500K | PWM DALI DMX Zigbee Manual |
| OAK-FL-200W | 200W | 418x320x70 | ||||
| OAK-FL-300W | 300W | 468x436x70 | ||||
| OAK-FL-400W | 400W | 568x436x70 | ||||
| OAK-FL-500W | 500W | 568x501x70 | ||||
| OAK-FL-600W | 600W | 568x566x70 | ||||
| OAK-FL-720W | 720W | 668x566x70 | ||||
| OAK-FL-800W | 800W | 668x631x70 | ||||
| OAK-FL-1000W | 1000W | 718x696x70 |
300W OAK LED Flood lights widely use in indoor and outdoor tennis court and others sport fields lighting projects.
